Operation and Application
4.9.6 Set the Output Timer Function
You can set the output timer within the range from 10ms to 10000000ms. Once
the timer expires, the output is turned off.
The procedures to set the output timer are as follows.
1. Press the composite keys [Shift] + [I-set](Function) to enter function menu
interface.
2. Use knob or left and right keys to select Off Timer and press [Enter] to
confirm.
3. Use knob or left and right keys to select On to turn the timer function on and
press [Enter] to confirm.
4. Use knob to adjust the output Timer and press [Enter] to confirm.
5. Press [Esc] to exit the function menu setting.
4.10 Protection Function
4.10.1 Set the Over-Voltage Protection (rms)
The user can set the over-voltage protection point for the over-voltage protec-
tion (rms) function. When the output voltage reaches the over-voltage protection
point, the over-voltage protection (rms) will turn off the output. The function is
mainly used to protect the DUT connected during test to prevent it from damage
due to over-voltage. The OVP (rms) function is always enabled.
Set the OVP(rms) point
1. Press the composite keys [Shift] + [F-set](Protect) to enter Protect menu
interface.
2. Rotate the knob to select OVP(rms) and press [Enter] key to confirm.
Copyright © Itech Electronic Co., Ltd.
71
