Quick Reference
Display is only used to prompt that the [Select] key is the display switch key
of the AC main interface, and has no other functions.
Composite key [Shift], combined with other keys to realize functions marked
above keys. The detailed functions are listed as follows.
Table 1–2 Composite keys Description
Key Name Description
[Shift]+[V-set](Config) Enter the Config menu.
[Shift]+[I-set](Function) Enter the Function menu.
[Shift]+[DC](System) Enter the System menu.
[Shift]+[F-set](Protect) Enter the Protect menu.
[Shift]+[On/Off]
(Trigger)
Generate a local trigger signal.
[Shift]+[Enter](lock) Turn the keyboard lock on or off.
[Shift]+
(Save)
Saves the present settings.
[Shift]+
(Recall)
Returns the instrument to the specified setup.
1.4 Rear Panel at a Glance
The rear panel of this series instruments is shown below.
• IT-M7721/IT-M7722/IT-M7721L/IT-M7722L/IT-M7722D rear panel
• IT-M7723 rear panel
