Technical Specification
Parameter IT-M7722D
Dimension (WxHxD)
Without foot post,
protective cover
215 × 44.45 × 450 mm
With foot post, pro-
tective cover
234 × 57.02 × 500 mm
Weight
5 KG
*1: Min voltage for THD test is 100Vac.
*2: Min voltage for frequency display accuracy is 100Vac.
*3: Tested with pure resistive load.
*4: This specification is applicable below ≤800Hz.
*5: The applicable range of frequency resolution is 45~99.9Hz.
7.5 IT-M7722E
Parameter IT-M7722E
AC Input
Voltage
100～240Vac
Phase
Single-phase
Frequency
47～63Hz
Max.current 15A
Power factor
0.99 (Typical)
AC Output
Max. output power
1000VA
Max. output voltage
300V
Output phase Single-phase
Current range(rms)
10A
Current range(peak)
45A
Output frequency range
45～1000Hz
Phase angle degree range
0～359.9°
THD*1*3
≤0.3% at 45～100Hz
≤1% at 101～800Hz
≤ (0.15%f-0.2)% at 801～1000Hz
Copyright © Itech Electronic Co., Ltd.
120
