Inspection and Installation
2.5.3.1 Using Http Server
The instrument has a built-in Http server for monitoring and controlling the in-
strument via a Http browser in PC. To use the Http server, connect the instru-
ment and PC over LAN interface and enter the instrument's IP address into the
address bar at the top of your PC's Http browser, you can access the front panel
control functions including the LAN configuration parameters.
• If you want to remotely control the instrument using the built-in Http server, you
must enable the Http service. See 2.5.3 LAN Interface for details.
• Up to six simultaneous connections are allowed. With additional connections,
performance will be reduced.
As shipped, the login password of the Http interface defaults to 12345678. To
change the password, click the Security button in the navigation bar on the left
side of the window after login.
Enter the password and then click the LOGIN button, the Http interface will ap-
pear in the browser as shown below.
You can select different interfaces by clicking the seven buttons shown in the
navigation bar on the left side of the window. The detailed descriptions are as
follows.
• Home: Http home interface, displays the model and appearance of the
instrument.
• Information: Displays the serial number of the instrument and more system
information as well as LAN configuration parameters.
Copyright © Itech Electronic Co., Ltd.
36
