ITech IT-M7700 Series User Manual

Operation and Application
Table 4–6 The as-shipped settings
Parameter Factory default value
Source
Vac 50V
Vdc 0V
OCP
• IT-M7721L/IT-M7721/IT-M7722D: 3A
• IT-M7722L/IT-M7722: 6A
• IT-M7723(V Range = High): 6A
• IT-M7723(V Range = Low ): 12A
• IT-M7723D: 7.5A
• IT-M7722E: 10A
• IT-M7723E: 15A
Freq 50.0Hz
Config menu
I Range Auto
(IT-M7721L/IT-M7722L/IT-M7723 does not
support this function.)
AC + DC Off
On Phase 0.0°
Off Phase 0.0°
V-Rise Time 1ms
Wave Sine (IT-M7721L/IT-M7722L does not support
this function.)
Parallel Single(Only IT-M7721/IT-M7722/IT-M7722D/
IT-M7723D/IT-M7722E/IT-M7723E support
this function.)
System menu
Beep On
PowerOn Last+Off
Relay Ctrl Out Syn
System Reset
No
Protect menu
Copyright © Itech Electronic Co., Ltd.
82
