jablotron JA-101K - 14 Supplementary Information; Overview Table of Current Consumption of BUS Devices

JA-101K(-LAN)(-LAN3G) and JA-106K(-3G)
Security System Control Panels 104 / 110 MLJ51410
14 Supplementary information
14.1 Overview table of current consumption of BUS devices
Device
Consumption in
the backup mode
(mA)
Consumption for
cable selection
Note
JA-110A Internal siren
5 30 30 mA during an alarm
JA-110B Glass fracture detector
5 5
JA-110F Flooding detector
5 5
JA-110I Section indicator / PG
3 6
JA-110M Connection module of a
magnetic detector
5 5
JA-110N PG module of power
output relay
5/45 5/45 Relay disengaged / engaged
JA-110N – DIN PG module of a
power output relay
5/45 5/45 Relay disengaged / engaged
JA-11xP PIR motion detector
5 5
JA-11xR Module for wireless
connection
25 25
JA-110ST Fire detector
5 10
JA-110T BUS isolator module
5 5
JA-111A External siren
5 50
In case of an AC supply
failure without battery charging,
otherwise 550 mA depending
on battery charge
JA-111H Detector connection
module
5 + consumption
of the connected
external sensor
5 + consumption
of the connected
external sensor
JA-111H-AD System control
module
5 + consumption
of the connected
external control
5 + consumption
of the connected
external control
JA-111I Universal optical indicator
5 5
JA-111ST Smoke and
temperature detector
JA-121T BUS interface for RS-485
10 20
JA-114HN BUS 4 I/O module
11 26
JA-116H Expander - 16 inputs
5/25 +
consumption of
connected external
sensors
5/25 +
consumption of
connected external
sensors
Connecting, disconnecting
inputs, inputs with simple or
double balancing
JA-118M Connection module of
magnetic detectors
5 15
Connecting, disconnecting,
balanced inputs
JA-111N PG module of a signal
output relay
5/25 5/25 Relay switched ON / OFF
JA-111SH Vibration or tilt detector
5 5
JA-112E RFID access module
10 15
JA-113E Access module with a
keypad and RFID
10 20
