JA-101K(-LAN)(-LAN3G) and JA-106K(-3G)
Security System Control Panels 56 / 110 MLJ51410
9.17 Non-alarm functions – Functions of PG outputs
The security system allows authorized users (according to the settings) to control the system functions – not
just functions related to guarding the sections but also controlling PG programmable outputs (switching
ON / OFF). Using relay modules or a module with special semiconductor outputs they can switch on devices
such as indicators, traffic lights, acoustic indicators, or other appliances related to the security system like lights,
systems for access control, blocking the heating when a window is open or when a section is set, garden
watering, etc., i.e. home automation.
Function of
PG output
Description Example
ON / OFF Bi-stabile output status, can
be changed by arbitrary
command or device
Manually switching ON appliances using a control segment,
SMS or also by some device with an option of manually
switching off with no limitation. Typically heating control,
air conditioning, lights
Impulse Mono-stabile output status
with pre-set time
Impulse switching of other additional control circuits such as
gate control, rollers, jalousies, garden watering, door locks,
etc.
Copy Output status with OR logic.
Output will be active
if minimum one device
at least will also be active,
but deactivation occurs when
all control devices will be
inactive.
Useful for indication of some single or collective statuses
(typically of open windows, garage doors, etc.) on the keypad
control segment.
In similar ways statuses of all sections, alarms, alarm
memories, faults and many other events can also
be indicated where the beginning and the end are given.
Delayed copy Mono-stable output status
with pre-set time of switching
with an option to be
prolonged repeatedly.
Typical output setting for control of lights when movement
is detected by a motion detector, any motion detected then
prolongs the pulse.
Extended
copy
Delayed output status with
pre-set time of that delay.
Mostly used for the indication of an opened door for longer
than a predefined time because someone could have
forgotten to close them (mains, door or garage door).
Indication can be optical on a keypad control segment
but also acoustic by keypad or indoor / outdoor siren.
Change Bi-stabile output status. Output meant for cyclical control (ON, OFF, ON,..)
for instance from an impulse device, by authorization
or by dialling in from an authorized telephone number.
The system also offers user functions such as measuring the temperature, which can be shown on the LCD
keypad and in the MyJABLOTRON application, measuring and monitoring electrical energy consumption,
amount of water or any other utilities. The JA-150EM-DIN impulse counter is for this purpose in combination
with some measuring device (electricity meter, gas meter, hydrometer, etc.). See our application studies and
recommendations in MyCOMPANY, MySTORAGE section.
