JA-101K(-LAN)(-LAN3G) and JA-106K(-3G)
Security System Control Panels 14 / 110 MLJ51410
3 Types of control panels, utility parameters
In the JA-100 system a few types of control panels are available. Their basic differences are summarized in
the table below.
Tab. 1
Feature / Type JA-101K(-LAN)(-3G) JA-106K(-3G) Note
Maximum number of devices 50 120
JA-106K max. 60 devices
per 1 BUS terminal
Maximum number of users 50 300
Maximum number of independent
sections (Partitions)
8 15
Maximum number of
programmable outputs
16 32
GSM / GPRS communicator Yes Yes
3G GSM module
alternative
IP LAN (Ethernet) communicator Yes Yes
Maximum number of
radio modules
3 3
SMS reports up to 8 users up to 25 users
Voice reports up to 8 users up to 15 users
Recommended 12 V
backup battery
2.6 Ah 18 Ah
Maximum continuous current
consumption available for devices
from the control panel
85 mA (with LAN)
125 mA (no LAN)
1200 mA
For 12 h backup supply
from the recommended
battery, the figure takes
into account the internal
consumption of the
control panel
Maximum possible short-term
current demand
1000 mA 2000 mA Max. for 5 min
BUS terminal(s)
1+RJ
connector
2+RJ
connector
The JA-106K terminals
are isolated, i.e. short-
circuiting of one branch
does not have any
influence on the other
branch.
The RJ connector is only
used to connect the radio
module directly in the
control panel.
Maximum BUS cable length 500 m 2 x 500 m
Can be extended using
the JA-110T modules
