JA-101K(-LAN)(-LAN3G) and JA-106K(-3G)
Security System Control Panels 95 / 110 MLJ51410
8. You can Save the Settings using the Save button (at the bottom on the right). If you are saving settings
in the control panel for the first time, SW will ask you to enter the file name. In the computer, a file with
the *FDB suffix will be created where the history of settings is gradually saved (every time the settings
are saved in the control panel). If you do not want to save the changes, select the Cancel button
and in the confirmation question select Ignore. Parameters can be changed in more tabs and you can
then Save all changes.
9. The Enroll not enrolled button (Lower toolbar on the Devices tab) will open a dialog for collective
enrollment (without the possibility to select positions) of devices that are connected to the BUS
and have not been connected to the system in another way. See chapter 8.4.1Enrolling and erasing
devices.
10. The Send enrolling signal button (Devices and PG outputs tab)will release sending of the enrolling
code of the control panel to wireless devices, e.g. to wireless output modules.
11. Setting of all parameters is only possible in the Service mode (the system is not in the active
setting mode. The Service mode is activated and deactivated with the Service button in the top toolbar.
12. Some parameters can be changed during operation. Therefore, the Settings tab can be opened
without entering the Service mode. However, available options can only be set.
13. The SW contains bubble help – after placing the mouse cursor over an item the text description
will be displayed. You can disable the bubble help in the F-Link roll-down menu.
Possible problems during the use of the System Settings:
Tab. 6
Problem Possible cause
None or some of the
displayed parameters cannot
be changed.
The system is not in the Service mode and you have selected a function that
can only be changed in the Service code.
On the start of the SW the Service Code was not entered and you
do not have the authorization.
This is a setting that cannot be changed (Service Technician’s authorization,
control panel position, the device does not support it etc.),
The ARC setting has been blocked by the ARC technician
You are offline
You have enabled the parameter fulfil the EN 50131 standard
The requested parameter
cannot be found
Only the basic options are displayed, use the Advanced button
You do not see the whole setting area on the screen – use a scroll button
or enlarge the window
You are authorized by a code with a different access level
The positions are arranged
in a different way
By clicking on the title of a column you can select which column will be used
as the criterion to arrange the positions; by clicking on the title repeatedly you
can select ascending or descending order.
Some tabs are missing
If the PG Outputs tab is not available, check whether the number of PG
outputs set in the Initial setting tab is not zero.
The ARC tab is not available if you do not have sufficient authorization
for it (it may be locked by the ARC technician).
It may also be unavailable after registration of the system in
the MyJABLOTRON application.
You have an older version of the F-Link(J-Link) software
Internal settings cannot be
modified in the Devices tab
Check whether the device is properly connected, enrolled and functional
The Service mode is not enabled
Some devices do not have internal settings
Older versions of F-Link may not have support for new types of devices
In the case of a wireless device check whether the radio module is enrolled
and functional
A device cannot be enrolled
in the Devices tab
For wireless devices – you have not enrolled the JA-11xR radio module
In a BUS device the yellow signal lamp must flash regularly. If it does not
flash, the element is not properly connected or has not stabilized after
activation of the power supply (it may take up to 180 s.).
The Service mode is not on
Older versions of F-Link may not have support for new types of devices
