Usingthefixturecontrols Abouttheconsolecontrols
 Triple clicking the clear button may leave the faders gated. This means that
the position of the fader does not match the channel output level. To un-gate
the fader you have to move it down or up to match the output level and take
control of the channel.
Shift
Press the Shift button and adjust the Hue and Saturation dials to the level of
any additional features assigned to these controls. For example:
If your fixtures have Strobe and Zoom features they will normally be assigned to
Shift + Saturation and Shift + Hue.
For information on assigning features to these controls see
Adding to the Fixture
Library
on page 4-5.
Shiftx2(Doubletapandhold)
Double tap and hold the Shift button and adjust a Hue dial to fan the colours
of all selected fixtures. The fan effect will depend on the Hue control you adjust,
for example:
If you have fixtures 1 to 12 selected and adjust the Hue control on Channel 1 the
fan will spread from Channel 12, which does not change colour, to the colour you
set on Channel 1.
If you adjust the Hue control on Channel 6 the fan will spread from Channel 1
and Channel 12, which do not change colour, inwards to Channel 6.
Double tap and hold the Shift button and adjust a Saturation dial to fan the
saturation of all selected fixtures.
 hile setting colours press the Undo button to revert
to the previous setting.
If you make a mistake w
Page
In Fixture channel mode there are 2 pages. Press the page button to switch
between the Black fixture page (Ch 1-12) and the White fixture page (Ch 13-24).
In Scene mode (see below) Stage CL can store up to 6 pages of Scenes (or
Chases) to the twelve Fixture faders. To switch between pages press the page
button. The LED indicates the 7 pages – p age 1 – Y
ellow, page 2 Red, page 3,
Green, page 4 Blue, page 5 Magenta, page 6 Cyan.
5‐4 StageCLUserGuide,Version1.3
