Janome JR3403N-AC

Specifications
Desktop Robot JR3000
 Host side: D-Sub 25 pin Connector
COM1: RS-232C Port
Robot Host (PC)
Pin No.
Terminal
Function
Pin No.
Terminal
Function
3
RxD
Receive Data
2
TxD
Transmit Data
2
TxD
Transmit Data
3
RxD
Receive Data
5
GND
Ground
7
GND
Ground
Connector: D-SUB 9 Pin Connector: D-SUB 25 Pin
COM2 (Optional): RS-232C Port
Robot Host (PC)
Pin No.
Terminal
Function
Pin No.
Terminal
Function
3
RxD
Receive Data
2
TxD
Transmit Data
2
TxD
Transmit Data
3
RxD
Receive Data
5
GND
Ground
7
GND
Ground
Connector: D-SUB 9 Pin Connector: D-SUB 25 Pin
COM3 (Optional): RS-232C Port
Robot Host (PC)
Pin No.
Terminal
Function
Pin No.
Terminal
Function
3
RxD
Receive Data
2
TxD
Transmit Data
2
TxD
Transmit Data
3
RxD
Receive Data
5
GND
Ground
7
GND
Ground
Connector: D-SUB 9 Pin Connector: D-SUB 25 Pin
100
