Janome JR3403N-AC

Specifications
Desktop Robot JR3000
4.2 Unit Fixtures (4 locations)
4.2.1 Common to the JR3200 Series
There are rubber feet attached (ϕ 30) in four places.
To secure the unit, use the M8 screws in the four places where the rubber feet are attached.
Note that dimensions within the brackets above are for reference only and may change depending
upon unit assembly.
(rubber foot)
(40.1)
275
(3)
210
4-M8
4 -φ 30
Example: JR3203N-AC
40
