17. TPU (TEACHING PENDANT CONNECTOR)

17.1 Connector

Teaching Pendant Connector

Robot Front

JR3200 Series

JR3300 Series/JR3400 Series

Example: JR3203N-AC

Example: JR3303N-AC

Teaching Pendant Connector
