13. I/O-MT (OPTIONAL)
I/O-MT is a connector that connects and controls externally attached devices such as a motor driver for
the motor etc. You can set up I/O functions and resolution etc. according to the devices you have. For
further details, please refer to the operation manual, Auxiliary Axis Functions.
13.1 Connector
NOTE
If you are using a JR3200 equipped with I/O-MT, you cannot use I/O-1.
I/O-MT (optional)
I/O-MT (optional)
Example: JR3203N-AC/BC
Example: JR3303N-AC/BC
Example: JR3203N-AC/BC
86
