2-M5
25
38
50
68
80
87
50.5
2-M4
4-M5
10
(Opening)
(20 depth)
(8 depth)
170 160
490
25-M4
80
160
80
160
120
2-φ5H6
(5 depth)
(4 depth)
A
B
Warning
Be sure to leave a space of 30cm or more between the rear of
the robot and the wall or any other obstacle when you install the
robot. If the robot is too close to the wall, etc. it will be hard to do
maintenance, etc., and also due to the cooling fan on the rear of
the unit, the robot may overheat or malfunction.
