Janome JR3403N-AC

Specifications
Desktop Robot JR3000
M4 screw holes (20)
M4 screw holes (16)
JR3300 Series
NOTE
Refer to “4. External Dimensions” for the dimensions of the M4 screw holes and the M4 nut T-slots.
JR3400 Series
Two vertical M4
nut T-slots
(4 sides on the
left and right)
Two vertical M4
nut T-slots
(3 sides)
Example: JR3403N-AC
Example: JR3303N-AC
47
