4-8
SM-18006
MAINTENANCE
TURN OFF all POWER supply switches.
Tool Phillips Screwdriver
(2) Removing Side Cover L
(a) Remove the service cover and front cover according to Section 4.1.1 “Removing Service Cover and
Front Cover”.
(b) Remove the upper cover according to Section 4.1.3 “Removing Upper Cover”.
(c) Remove the rear cover according to Section 4.1.4 “Removing Rear Cover”.
(d) Remove six screws attaching side cover L.
(e) Remove side cover L.
Side Cover L
