4.2.6 Thermistor
(1) Position of Thermistor
Te Thermistor for
Heat Exchanger
Liquid Side Temperature
Tchg Thermistor for
Liquid Stop Valve Temperature
Ta Thermistor for
Entering Water Temperature
Tg Thermistor for
Heat Exchanger
Gas Side Temperature
Ts Thermistor for
Electrical Box Temperature
(Inner Upper Side of Electrical Box)
Td Thermistor for
Upper Side of
Compressor Temperature
Tsc Thermistor for
Subcooler Inlet Temperature
