(Main Parts)
MAINTENANCE
SM-18006
4-79
●
Arrangement of Inverter Power Unit
(H,Y)VWH(P
,R)144B42S, (H,Y)VWH(P
,R)168B42S,
(H,Y)VWH(P
,R)192B42S and (H,Y)VWH(P
,R)216B42S Only
Inverter PCB (INV1)
Inverter PCB (INV2)
Radiation Plate 1
Radiation Plate 2
