(Main Parts)
MAINTENANCE
SM-18006
4-103
(2) Noise Filter for 460V Type
Items Specications
Model NF161Q
Rated Voltage AC 460V
Rated Current 25A
Circuit Diagram
R1
S1
T1
R2
S2
T2
inch (mm)
L1
L2
DC 500V 63A
DC 500V 63A
DC 500V 63A
R1
Z1
CX2
S1
Z2
Z3
CX3
T1
Cy3
Cy2
Z4
R2
CX4
S2
CX5
T2
CX6
Cy1
SA
NFT-040A25-HHA0
H7B04937A-D
CX1
E
JP
FU1
FU2
FU3
5-3/8 (137)
5-7/8 (150)
9-3/16 (233)
4-3/8 (111.5)
7-7/8 (200)
6-
φ
3/16 (4)
4-1/4 (108.5)
