Johnson Controls LSWU User Manual

JOHNSON CONTROLS
149
SECTION 6 – USER INTERFACE CONTROL CENTER
FORM 145.05-NOM7
ISSUE DATE: 10/31/2019
6
TABLE 31 - SUPPLY SYSTEM
DISPLAY TEXT
PASS
WORD
LEVEL
RANGE
DE-
FAULT
SHOW WHEN UNIT TYPE IS
Supply System
Status
Normal - Active Normal - Inactive
Safety Trip Safety Lockout
Always
Supply Fan
Output On - Off Derived
Always
Status Running Stopped Derived
Supply Fan VFD
Output 0.0 to 100% Derived
UNIT TYPE equals VARIABLE AIR VOL-
UME or FLEXSYS
Freq 0.0 to 60Hz Derived
Duct Static Press
Current 0.00 to 5.00 "W.C.
Look Up
Table
UNIT TYPE equals VARIABLE AIR VOL-
UME or FLEXSYS and Duct Pressure
Sensor 2 is set to DISABLED
Active SP 0.00 to 5.00 "W.C. Derived
Duct Static
Press 1 0.00 to 5.00 "W.C.
Look Up
Table
UNIT TYPE equals VARIABLE AIR VOL-
UME or FLEXSYS and Duct Pressure
Sensor 2 is set to ENABLED
Press 2 0.00 to 5.00 "W.C.
Look Up
Table
Duct Static Press
Average 0.00 to 5.00 "W.C.
Look Up
Table
UNIT TYPE equals VARIABLE AIR
VOLUME or FLEXSYS, Duct Pressure
Sensor 2 is set to ENABLED, and Duct
Press Cntrl is set to AVERAGE.
Active SP 0.00 to 5.00 "W.C. Derived
Duct Static Press
Lowest 0.00 to 5.00 "W.C.
Look Up
Table
UNIT TYPE Equals VARIABLE AIR
VOLUME or FLEXSYS, Duct Pressure
Sensor 2 is set to ENABLED, and Duct
Press Cntrl is set to LOWEST.
Active SP 0.00 to 5.00 "W.C. Derived
Duct Static Press
Highest 0.00 to 5.00 "W.C.
Look Up
Table
UNIT TYPE Equals VARIABLE AIR
VOLUME or FLEXSYS, Duct Pressure
Sensor 2 is set to ENABLED, and Duct
Press Cntrl is set to HIGHEST.
Active SP 0.00 to 5.00 "W.C. Derived
