SECTION 6 – USER INTERFACE CONTROL CENTER
DATE / TIME
To change the day, time, and date press the DATE/
TIME key. The ▼ key is used to scroll to the next item
to be programmed and the ▲ key scrolls to the previ-
ous item. The following messages are displayed. The
first line is an active display and the second line is the
entry line.
Clock Fri 18 Jun 2004 10:15:33 AM
Day of Month =XX
Clock Fri 18 Jun 2004 10:15:33 AM
Month =XX
Clock Fri 18 Jun 2004 10:15:33 AM
Year =XXXX
Clock Fri 18 Jun 2004 10:15:33 AM
Hour =XX
Clock Fri 18 Jun 2004 10:15:33 AM
Minute =XX
Clock Fri 18 Jun 2004 10:15:33 AM
Day of Week =XXX
Clock Fri 18 Jun 2004 10:15:33 AM
12 Hour Period =XX
Clock Fri 18 Jun 2004 10:15:33 AM
Time Format =XXXXXXX
Clock Fri 18 Jun 2001 10:15:33 AM
Power Off Time =XXXXX
Follow the instructions given in the Data Entry Keys
section to change the above values.
SCHEDULE
The “clock schedule” function can be USER EN-
ABLED /
USER DISABLED by using the schedule
screen below.
To set the schedule, press the SCHEDULE key. The
display shows the following message:
Schedule  To Edit
Occupancy Schedule User Enabled
Schedule Mon  To Edit
+Start =06:00 AM Stop =10:00 PM
Schedule Tue  To Edit
Start =06:00 AM Stop =10:00 PM
Schedule Wed  To Edit
Start =06:00 AM Stop =10:00 PM
Schedule Thu  To Edit Start =06:00 AM
Stop =10:00 PM
Schedule Fri  To Edit
Start =06:00 AM Stop =10:00 PM
Schedule Sat  To Edit
Start =06:00 AM Stop =10:00 PM
Schedule Sun  To Edit
Start =06:00 Am Stop =10:00 Pm
To change the start or stop time, press the  key. The
line under the 0 is the cursor. If the start time is wrong,
it may be changed from the numeric keypad. Once the
correct value (hour and minute) is entered, press the 
key. The cursor moves to the AM/PM selection. This
value may be chosen by the +/- key and entered by
pressing the  key. This process may be followed until
the hour, minutes, and meridian of both the START and
STOP points are set. Press the ▼ key to get the sched-
ule for the next day to appear. The start and stop time of
each day may be programmed differently. If you want
to view the schedule without making a change, simply
press the ▼ key until the day you wish to view appears.
The ▲ key scrolls backwards to the previous screen.
If you want to provide continuous operation from one
