JOHNSON CONTROLS
28
FORM 145.05-NOM7
ISSUE DA
TE: 10/31/2019
SECTION 2 – INST
ALLA
TION
90.00 REF
35.00 REF
100.00 REF
TOP VIEW
LIFTING POINT
LIFTING POINT
LIFTING POINT
LIFTING POINT
SHIPPING TIMBERS
LIFTING POINTS
LIFTING POINTS
LD21638
FIGURE 17 -
LIFTING RECOMMENDA
TIONS, COIL
SECTION ONL
Y (LSW_050–060)
27
29
