JOHNSON CONTROLS
36
FORM 145.05-NOM7
ISSUE DATE: 10/31/2019
SECTION 2 – INSTALLATION
TABLE 5 - OPERATING WEIGHTS (LSW_025–060)
MODEL 025 032 035 040 050 060
Coil Section 1,832 1,890 1,941 2,032 3,536 3,656
Water Economy Coil Option 320 378 442 442 711 711
High Efficiency Option 20 25 30 45 70 80
Fan Section 984 984 984 984 1,380 1,380
Supply Fan
25 Inch Class II N/A 358 358 358 N/A N/A
28 Inch Class II 273 273 273 273 N/A N/A
32 Inch Class II N/A N/A N/A N/A 427.9 428
36 Inch Class II N/A N/A N/A N/A 582.59 583
40 Inch Class II N/A N/A N/A N/A N/A N/A
Filter Section
4 inch 30-35% Efficiency (MERV 8) 156 156 156 156 205 205
4 inch 60-65% Efficiency (MERV 11) 178 178 178 178 265 265
4 inch 60-65% Eff + 4 inch 30-35% Eff Prefilter
(MERV 11 + 8)
288 288 288 288 391 391
4 inch 90-95% Eff + 4 inch30-35% Eff Prefilter
(MERV 14 + 8)
288 288 288 288 391 391
Plenums
Inlet Plenum - Sound Attenuating 246 246 246 246 290 290
Air Economizer 678 678 678 678 866 866
Outlet Plenum - Half 295 295 295 295 355 355
Outlet Plenum - Full 386 386 386 386 415 415
TABLE 6 - SUPPLY FAN MOTOR WEIGHTS
HP
ODP TEFC
HI-EFF PREMIUM EFF HI-EFF PREMIUM EFF
5 HP 160 175 169 199
7.5 HP 193 207 219 260
10 HP 220 238 239 341
15 HP 327 327 349 365
20 HP 317 367 389 421
25 HP 385 470 572 538
30 HP 427 512 580 573
40 HP 532 614 595 742
50 HP 540 622 729 900
60 HP 637 848 877 964
NOTES:
1. All weights are in Lbs.
2. Add waterside economizer weight, if selected, to coil section.
3. Add selected fan, motor, and VFD weight to the fan section weight to get total fan weight.
4. Add coil section, fan section and lter section weights together to obtain total unit weight.
