SECTION 2 – INSTALLATION
FIGURE 27 - UNIT DIMENSIONS, TOP DISCHARGE, ASSEMBLED (LSWU 050–060)
075-83756-901 REV B
NOTES: 1. Due to the dedication of continuous product improvement and enhancements, the information/dimensions provided are subject to change without notice. 2. All dimensions are in inches.
* Discharge Opening
** 2.63 inch OD Copper Grooved connections *** 1.63 inch Copper Male Sweat Connections
Optional Coil
Section Door
s
“A”
48.94
76.00
43.91
33.49 *
6.80
16.15
6.58
51.67 *
99.94
46.30
1.63 Lifting Lug
Condenser Water Out **
Hot Water Out ***
Hot Water In ***
Condenser Water In **
Std. Dia. 1.00 Nom. PVC socket (to connect metal pipe, plastic weld one universal P/N 478-010 spigot female adapter)
Optical Unit VFD Display
75.62
90.00
14.26
DRAIN CONNECTION (DE
TAIL “B”)
DUCT CONNECTION OPTION
(Showing Duct Inside Dimensions)
Drain piping connection (see Detail “B”)
71.25
16.19
85.72
7.86
3.69
SUPPLY
AIR
AIR IN
DETAIL “A”
26.69
25.44
24.19
.88
2.86
2X 1.38
Electrical Penetrations (see Detail “A”)
Disconnect Switch Toggle
Keypad & Display
5.92
0.34
4.45
Optional VFD
Electrical Compartment Door
Fan Access Door
Compressor & Coil Access Door
Coil Section Access Panel
50.44
10.14
NO. FILTER OPTIONS "A"
1 4 inch lter 82.00 2
4 inch prelter + 4 inch high
efciency lter
86.25
