Johnson Controls York YKEP Series User Manual

FORM 160.77-O2
ISSUE DATE: 11/15/2011
SECTION 4 - MODBUS RTU SLOT LIST
JOHNSON CONTROLS
107
4
Modbus DF1 Count Logix Tag Description
10540 N12:27/8 440 VSD_LS.Alarms[3].8 PRI VSD FAULT: W3 B8
10541 N12:27/9 441 VSD_LS.Alarms[3].9 PRI VSD FAULT: W3 B9
10542 N12:27/10 442 VSD_LS.Alarms[3].10 PRI VSD FAULT: W3 B10
10543 N12:27/11 443 VSD_LS.Alarms[3].11 PRI VSD FAULT: W3 B11
10544 N12:27/12 444 VSD_LS.Alarms[3].12 PRI VSD FAULT: W3 B12
10545 N12:27/13 445 VSD_LS.Alarms[3].13 PRI VSD FAULT: W3 B13
10546 N12:27/14 446 VSD_LS.Alarms[3].14 PRI VSD FAULT: W3 B14
10547 N12:27/15 447 VSD_LS.Alarms[3].15 PRI VSD FAULT: W3 B15
40200 N7:00 0 BAS_INT_Analogs[0 PRIMARY Motor Current
40201 N7:01 1 BAS_INT_Analogs[1 ECONOMIZER MOTOR Current
40202 N7:02 2 BAS_INT_Analogs[2 Evaporator Refrig. Pressure
40203 N7:03 3 BAS_INT_Analogs[3 Condenser Refrig. Pressure
40204 N7:04 4 BAS_INT_Analogs[4 Economizer Refrig. Pressure
40205 N7:05 5 BAS_INT_Analogs[5 Compressor Sump Oil Pressure
40206 N7:06 6 BAS_INT_Analogs[6 spare 6
40207 N7:07 7 BAS_INT_Analogs[7 PRIMARY Compressor High Oil Pressure
40208 N7:08 8 BAS_INT_Analogs[8 ECONOMIZER COMPRESSOR High Oil Pressure
40209 N7:09 9 BAS_INT_Analogs[9 spare 9
40210 N7:10 10 BAS_INT_Analogs[10 spare 10
40211 N7:11 11 BAS_INT_Analogs[11 Subcooler Refrig. Liquid Level
40212 N7:12 12 BAS_INT_Analogs[12 Economizer Refrig. Liquid Level
40213 N7:13 13 BAS_INT_Analogs[13 PRI Comp SEC Thrust Bearing Probe Gap
40214 N7:14 14 BAS_INT_Analogs[14 System Kilowatts
40215 N7:15 15 BAS_INT_Analogs[15 PRIMARY PRV Position
40216 N7:16 16 BAS_INT_Analogs[16 SECONDARY PRV Position
40217 N7:17 17 BAS_INT_Analogs[17 Hardwired Remote Chilled Water Setpoint
40218 N7:18 18 BAS_INT_Analogs[18 Chilled Water Out Temperature
40219 N7:19 19 BAS_INT_Analogs[19 Chilled Water In Temperature
40220 N7:20 20 BAS_INT_Analogs[20 Condenser Water Out Temperature
40221 N7:21 21 BAS_INT_Analogs[21 Condenser Water In Temperature
40222 N7:22 22 BAS_INT_Analogs[22 Evaporator Refrig. Liquid Temperature
40223 N7:23 23 BAS_INT_Analogs[23 PRI Comp Refrig. Discharge Temperature
40224 N7:24 24 BAS_INT_Analogs[24 SEC Comp Refrig. Discharge Temperature
40225 N7:25 25 BAS_INT_Analogs[25 Subcooled Refrig. Liquid Temperature
40226 N7:26 26 BAS_INT_Analogs[26 Compressor Oil Sump Temperature
40227 N7:27 27 BAS_INT_Analogs[27 Primary Motor VSD speed in Hertz
40228 N7:28 28 BAS_INT_Analogs[28 Five Volt Supply
40229 N7:29 29 BAS_INT_Analogs[29 Hardwired Remote Demand Limit Setpoint
40230 N7:30 30 BAS_INT_Analogs[30 PRI VGD Pressure Sensor / Intermediate Pressure
40231 N7:31 31 BAS_INT_Analogs[31 PRI VGD Stall Noise Level
40232 N7:32 32 BAS_INT_Analogs[32 PRI VGD Position
40233 N7:33 33 BAS_INT_Analogs[33 SEC VGD Pressure Sensor
40234 N7:34 34 BAS_INT_Analogs[34 SEC VGD Stall Noise Level
40235 N7:35 35 BAS_INT_Analogs[35 SEC VGD Position
40236 N7:36 36 BAS_INT_Analogs[36 Hot Gas Bypass Valve
