– 19 –
(4) Cleaning the hook lubrication lter (oil wick)
1) Loosen lubrication connecting screw to remove
it.
2) Pull out pipe of lubrication connection joint .
3) Take out lter from lubrication connection joint
.
4) Remove stains from lter or replace it with a
new one.
5) Take out oil wicks and from lubrication con-
nection screw and pipe .
6) Remove stains from oil wicks and or replace
them with new ones.
Filter and oil wicks and should be
cleaned when the oil quantity in the hook
has decreased or periodically about once
a month.
If it has stained heavily, change the oil wick
with a new one.
If the lter is clogged, the hook cannot
be oil adequately, resulting in a machine
failure.
