Table 43: Multilink Bundles Supported by ACX Series Routers

Maximum Links Per

BundleMaximum LinksMaximum BundlesACX Platform

161616ACX2000

ACX2100

161616ACX4000

ACX-MIC-16CHE1-T1-CE

1633650ACX4000

ACX-MIC-4COC3-1COC12CE

888ACX1000

The following rules apply when you add constituent links to a multilink bundle:

•

On each multilink bundle, add only interfaces of the same type. For example, you can

add either T1 or E1, but not both.

•

Only interfaces with a PPP encapsulation can be added to an MLPPP bundle.

•

If an interface is a member of an existing bundle and you add it to a new bundle, the

interface is automatically deleted from the existing bundle and added to the new

bundle.

With multilink PPP bundles, you can use PPP Challenge Handshake Authentication

Protocol (CHAP) and Password Authentication Protocol (PAP) for secure transmission

over the PPP interfaces. For link services IQ (lsq) interfaces only, the maximum number

of multilink classes to be negotiated when a link joins the bundle that you can specify by

using the multilink-max-classes statement at the [edit interfaces interface-name unit

logical-unit-number] hierarchy level is limited to 4. Fragmentation size is not specified

under fragmentation map; instead, fragmentation size configured on the bundle is used.

Compressed Real-Time Transport Protocol (RTP) is not supported. HDLC address and

control field compression (ACFC) and PPP protocol field compression (PFC) are not

supported.

Documentation

Link and Multilink Services Overview•

• Multilink Interfaces on Channelized MICs Overview
