Juniper CTP Series User Manual

To display buffer for a CTP bundle using the CTP Menu:
1. From the CTP Main Menu, select 1) Bundle Operations.
2. Select the type of bundle.
3. Select a bundle from the list.
4. Select 8) Runtime Diags.
5. Select 8) Buffer Query.
A list of buffer counts appears. Table 61 on page 155 describes the fields in the buffer
counts.
Table 61: Buffer Counts for CTP Bundles in the CTP Menu
DescriptionField Name
Number of packets measured since the last time the count was cleared.Total Samples
Within the total number of samples, the smallest sample measured in milliseconds.
Packets in this sample experienced the most delay.
Smallest Sample
Within the total number of samples, the average buffer fill, in milliseconds.Average Sample
Within the total number of samples, the largest sample measured in milliseconds. Packets
in this sample experienced the least delay.
Largest Sample
Difference between the largest sample measured and the smallest sample measured, in
milliseconds. This number corresponds to system packet delay jitter.
Largest Buffer Jitter
155Copyright © 2018, Juniper Networks, Inc.
Chapter 5: Monitoring Packet Creation and Reception and Packet Delay for CTP Bundles
