KAESER M 64 - Chassis; Chassis Options; Machines with Stationary Frame Design; Mass of Machines with Stationary Frame Design

■ track width,
■
footprint,
are to be found in the dimensioned drawing in chapter 13.3.
The dimensional drawings also show the position of the following inlets and outlets:
■
Cooling air inlet
■ Cooling air outlet
■ Compressed air outlet
■ Exhaust
2.4 Chassis
2.4.1 Chassis options
➤ Chassis instructions are found in the separate chassis documentation.
2.5 Machines with stationary frame design
2.5.1 Option rw, rx
Mass of machines with stationary frame design
Actual mass of individual machines are dependent on equipment fitted (see machine nameplate).
➤
Enter the actual overall weight* from the nameplate as reference.
Option rw rx
Type stationary frame de‐
sign
Skids Frame
Actual total weight [kg]*
* Enter here for reference, the actual total weight taken from the nameplate.
Tab. 24 Mass of the machine
2.6 Compressor
2.6.1 Working pressure and FAD
Maximum working gauge pressure [bar] 7 10
SIGMA airend 270 260
Free air delivery [m
3
/min]
6.4 5.0
FAD as per ISO 1217:2009. Annex D
Tab. 25 Working pressure and FAD
2 Technical Specifications
2.4 Chassis
10
Operator manual Portable compressor
M 64 No.: 9_5898 26 E
