KAESER M 64 - Fig. 24 Insulation Monitoring - 115 V, Single-Phase Generator (50 Hz); Fig. 25 Insulation Monitoring - 230 V, Single-Phase Generator (60 Hz)

Fig. 24 Insulation monitoring - 115 V, single-phase generator (50 Hz)
Fig. 25 insulation monitoring - 230 V, single-phase generator (60 Hz)
1 «Main switch»
2 «Operating mode selector switch»
3 Test button with
earth leak warning lamp
for «insulation monitoring»
4
«Mains circuit breaker»
(«Circuit breaker»
designed as automatic
circuit-breaker with shunt trip)
5/6
Single-phase power sockets
1. Start the machine.
2. DANGER!
Risk of fatal injury caused by contact with live components!
➤
The generator may only be used if the «circuit breaker» («mains circuit breaker») has trip‐
ped during the test!
7 Initial Start-up
7.5 Putting the generator into operation
No.: 9_5898 26 E
Operator manual Portable compressor
M 64
67
