6) While holding down the pump start
button, lower the gooseneck separation
console from the 1 and 2 levers.
Lowering the gooseneck separation console
The gooseneck separation
console must press on a flat
surface on the truck. If the
ground on the tractor is not
flat, place a support (1) under
the console so that it presses
flat.
Pressing the separation console on a flat surface
If the cylinder stroke of the
gooseneck release console is
short, place a support under
the console to ensure that the
cylinders operate
comfortably.
7)Remove the safety pin and the goose-
neck pin shown in the picture. If there is
difficulty in removing the pin, the goose-
neck is moved up and down to release
the pin.
Pulling the safety pin
8) In order to bring the pool and goose-
neck of the vehicle to the separation po-
sition, bring the gooseneck hydraulic
cylinders to the fully closed position by
lowering the pump start button and the
number 3 lever.
Pump start button
Hydraulic control lever
