SYSTEM DESCRIPTION
2 System Description
The COMBIVIS connect router is a device that is able to support the remote services as
a stand-alone solution. It enables the use of COMBIVIS connect in all those situations
where for any reason the software solution is not an option. COMBIVIS connect Router
device applies to the automation network with zero impact on the actual devices. No
changesarerequestedtothecongurationofanyoftheexistingdevices.
COMBIVISConnectRouterimplementsaspecicvariantofCOMBIVISconnectRunt-
ime; from the functional point of view this is equivalent to the standard Runtime concepts.
2.1 Special features
•
KEB COMBIVIS connect Router runtime on Microsoft Windows Embedded Com-
pact 7.
•
Full compatibility with standard COMBIVIS connect software functions (see COM-
BIVIS connect Control Center online manual for further information).
•
ARM Cortex A8 processor (1.0 GHz, 800MHz for ET version).
•
512MB RAM DDR3-800
•
2/4GBeMMCmemory,lesystemorganizationfordatastorage
•
Ethernet interface 10/100 Mbps WAN for Internet connection.
•
Ethernet interface 100 Mbps LAN for the automation network.
•
RS-232/RS-485/RS-422 optically isolated serial port with MPI support up to 187
Kbit/s.
•
USB2.0interfaceforsystemcongurationandupdates.
•
Front panel LEDs for device status and operation report.
•
24 VDC Digital input to control COMBIVIS connect Router device WAN connec-
tion activation.
•
24 VDC Digital input for COMBIVIS connect Router device software reset.
•
Digital output to report the status of the WAN connection to the COMBIVIS con-
nect Server Infrastructure.
•
Digital output to report remote the presence of a Control Center connection (Re-
mote assistance service running).
•
Stainless steel housing
•
DIN rail book mounting and wall book mounting.
•
Degree of protection IP 20
