KEB C6 Instructions For Use

57
TECHNICAL SPECIFICATIONS
6 Technical Specications
6.1 Technical data
System software characteristics
Integrated system software Operating system Microsoft Windows Embedded Compact 7 (C7P)
Other software KEBCOMBIVISconnectruntimermware
Table 1: System software characteristics
System hardware characteristics
Motherboard Model All-in-one, KEB R171
RTC Hardware with battery backup
CPU C6 Router E1 Processor ARM Cortex A8 - Freescale i.MX535 - 1 GHz
Memory bus 400 MHz
CPU C6 Router
E1ET
Processor ARM Cortex A8 - Freescale i.MX537 - 800 MHz
Memory bus 400 MHz
System memory Type/size/sock-
et
512 MB, / DDR3-800 / soldered
Serial port Type 1 x RS232/422/485 (DB15M) software selectable
Optoisolation Yes
Ethernet interfaces Type 1 x 10/100Mbps WAN (RJ45) with link/activity leds
1 x 100Mbps LAN (RJ45) with link/activity leds
3G/4G modem (only for C6 Rout-
er L1-L4)
Type provides data service under global GSM/GPRS/EDGE/
WCDMA networks (14.4Mbps Downlink data rate)
USB interfaces Type 1xUSB2.0(TYPE-A,hostport,softwareswitcho󰀨)
Mass storage Internal / not
removable
NAND-FLASH:
256 MB (read only) for operating system and other
system software.
eMMC:
2/4 GB - 8 Bit v. 4.4 compatible (application software
and COMBIVIS connect Runtime).
Battery Type Coin (CR1220 3V) removable, non rechargeable.
Lifetime 3 years
Buttons, LEDs and keys Reset button System
Factory recov-
ery button
User
