COMMISSIONING
To transfer the project click on the button “Upload Project”. Once the transfer is complet-
ed, click “Start Device Project” to run the application.
the name of the memory are according to the following table:
Memory
Name used by the user
system
Note
NAND NANDFlash
Internal memory used to store the oper-
ating system.
It is a read-only memory.
MMC MMCMemory
For saving data and executable pro-
grams.
Read and Write memory.
Figure 46: COMBIVIS connect Router E2/L2 models
Please refer to the "COMBIVIS connect Software User Manual" for additional informa-
tion on retrieving data loggers of the E2/L2 router systems.
COMBIVIS connect E2/L2 models with integrated 2G/3G/3G+ modem support
theSMSalarmnotication;theCOMBIVISHMIalarmdispatchersoftwareis
alreadyconguredtousetheinternalmodem.Youonlyneedtocongurethe
alarm thresholds according to the application requirements. Please see the
COMBIVIS studio HMI online help for further information about how to setup
alarmnoticationviaSMS.
COMBIVIS connect E2 models without integrated modem, DO NOT support
alarmnoticationviaSMS.Onlye-mailnoticationsaresupported.
