KEB C6 Instructions For Use

60
TECHNICAL SPECIFICATIONS
6.3 Wall mount Panel antenna characteristics
Mains form
Frequency (MHz) 824 ~ 896 880 ~ 960 1710 ~ 1880 1850 ~ 1990 1710 ~ 2170
Peak gain (dBi)
Free space -0.7 -0.9 1.7 2.5 2.2
L-angle bracket 4.0 3.6 2.8 3.8 3.3
Average gain (dBi)
Free space -5.7 -5.3 -2.2 -2.1 -2.3
L-angle bracket -1.7 -1.8 -2.2 -1.7 -1.9
E󰀩ciency
Free space 27 % 30 % 61 % 62 % 60 %
L-angle bracket 69 % 66 % 59 % 68 % 65 %
Impedance 50Ω
Polarization Linear
Radiation pattern Omni-directional
Input power 50 W
Mechanical
Dimensions Height 248 ± 5 mm
Base diameter 17.08 ± 0.2 mm
Whip diameter 4 ± 0.2 mm
Housing ABS
Connector SMA connector
Environmental & mechanical
Temperature range -40° to +85°C
Humidity Non condensing 65°C 95% RH
Table 8: Wall mount Panel antenna characteristics
