SYSTEM DESCRIPTION
2.11 Antenna
2.11.1 Pentaband stilo antenna
• C6 Router direct mounting or panel mounting with extension cable
• 20 W
• 0dBi
• 50 Ohm
• 48 mm
• SMA-M
Figure 15: C6 Router Pentaband stilo antenna features
Figure 16: C6 Router Pentaband stilo antenna
2.11.2 Pentaband wall mounting antenna
• 3 m cable
• Wall mounting with 90° bracket
• IP 67
• 50 W
• 2.5dBi
• 50 Ohm
• 248 mm
• SMA-M
Figure 17: C6 Router Pentaband stilo antenna features
Figure 18: C6 Router Pentaband wall mounting antenna
