59
TECHNICAL
SPECIFICA
TIONS
6.2
Panel antenna characteristics
Electrical
Frequency range
800MHz to 2200MHz
Bands
GSM-DCS-PCS-UMTS-CDMA-GPRS-EDGE-HSP
A
VSWR
≤2.3
Polarization
Linear
Power handling
20 W
Impedance
50 Ohm
Connector
Straight SMA(M)
T
able 6:
Panel antenna characteristics
Environmental & mechanical
T
emperature
-40° to +85°C
Radome color
black
Radome material
Pu
Weight
6 g
T
able 7:
Panel antenna characteristics
58
60
Table of Contents
Default Chapter
3
Preface
3
Signal Words and Symbols
3
More Symbols
3
Laws and Guidelines
4
Warranty and Liability
4
Support
4
Copyright
4
Table of Contents
5
List of Figures
8
List of Tables
10
Glossary
11
Standards for Control & Automation
12
1 Basic Safety Instructions
14
Target Group
14
Transport, Storage and Proper Use
15
Installation
15
Electrical Connection
16
Start-Up and Operation
16
Maintenance
16
Repair
17
Disposal
17
2 System Description
18
Special Features
18
Router Package
19
Figure 1: Router Package
20
Front View C6 Router E1 - E4
21
Figure 2: Front Detail
21
Figure 3: C6 Router E1-E4 Front View
22
Front View C6 Router L1-L4
23
Figure 4: Front Detail
23
Close-Up View C6 Router L1-L4
25
Figure 5: C6 Router L1-L4 Front View
25
Figure 6: C6 Router L1-L4 Close-Up View
25
Figure 7: C6 Router L1-L4 Features
26
Right Side C6 Router L1-L4
27
Left Side C6 Router L1-L4
27
Figure 8: C6 Router L1-L4 Right Side
27
Figure 9: C6 Router L1-L4 Left Side
27
Rear Side C6 Router L1-L4
28
Rear Side C6 Router E1-ET, E2-ET and E1-E4
28
Figure 10: C6 Router L1-L4 Rear Side
28
Figure 11: C6 Router E1-ET, E2-ET and E1-E4
28
Labels
29
Figure 12: C6 Router Labels
29
Figure 13: C6 Router Labels
30
Figure 14: C6 Router SIM Card Sticker
30
Antenna
31
Pentaband Stilo Antenna
31
Pentaband Wall Mounting Antenna
31
Figure 15: C6 Router Pentaband Stilo Antenna Features
31
Figure 16: C6 Router Pentaband Stilo Antenna
31
Figure 17: C6 Router Pentaband Stilo Antenna Features
31
Figure 18: C6 Router Pentaband Wall Mounting Antenna
31
Pentaband Outdoor Antenna
32
Figure 19: C6 Router Pentaband Stilo Antenna Features
32
Figure 20: C6 Router Pentaband Wall Mounting Antenna
32
3 Installation and Connection
33
Preparation for Installation
33
Select the Mounting Location
33
Checking the Package Contents
33
Checking the Operating Conditions
33
Installation Position
33
Damage Due to Overheating
34
Preparing the Mounting
34
Mounting the Device
34
Installation Procedure Wall Mounting
34
Figure 21: Wall Mounting Procedure
34
Figure 22: Wall Mounting Procedure / DIN Rail Mounting
34
Figure 23: Wall Mounting Procedure / DIN Rail Mounting
35
Figure 24: Wall Mounting Procedure / DIN Rail Mounting
36
Wall Mounting Procedure DIN Rail Mounting
37
Figure 25: Wall Mounting Procedure / DIN Rail Mounting
37
Figure 26: Wall Mounting Procedure / DIN Rail Mounting
38
Figure 27: Wall Mounting Procedure
38
SIM Installation
39
Figure 28: SIM Installation
40
Antenna Installation
41
Pentaband Stilo Antenna
41
Figure 29: Pentaband Stilo Antenna
41
Pentaband Wall Mounting Antenna
42
Pentaband Outdoor Antenna
42
Figure 30: Pentaband Wall Mounting Antenna
42
Figure 31: Pentaband Outdoor Antenna Installation
42
Connecting the Device
43
Notes on Connection
43
Grounding and Bonding
43
Power Supply Connection
43
Connecting the Ethernet Ports
44
Switching on and Testing the COMBIVIS Connect Router Device
44
Figure 32: Connections for the Power Supply
44
Figure 33: Connections for the Ethernet Ports
44
Connecting the Serial Port
45
Connecting to MPI or PPI Networks
45
Figure 34: Connections for the Power Supply
45
Figure 35: DB9 Connection Adapter
45
Figure 36: Adapter Cable
46
Figure 37: Connection Adapter Cable
46
Connecting the Digital Inputs and Outputs (I/O)
47
IN0 - WAN Connection Enabling Security Key
47
IN1-Reset Input
47
Figure 38: IN0-WAN Connection Example for Activating a Security Key
47
Figure 39: IN1-Reset Input
47
OUT0-WAN Connection to Activate Signalling Equipment
48
Figure 40: OUT0-WAN to Activate Signalling Equipment
48
Figure 41: OUT0-WAN to Activate Signalling Equipment
48
OUT0 - Remote Assistance Service Running
49
Figure 42: OUT0-Remote Services Application
49
Figure 43: OUT0-Remote Services Application
49
4 Commissioning
50
Configuration
50
COMBIVIS Connect Router E2/L2 Models
50
Figure 44: COMBIVIS Connect Router E2/L2 Models
51
Figure 45: COMBIVIS Connect Router E2/L2 Models
51
Figure 46: COMBIVIS Connect Router E2/L2 Models
52
5 Maintenance
53
Maintaining and Cleaning
53
Backup Battery Replacement (CR1220 3V)
53
Figure 47: Backup Battery Replacement
53
Figure 48: Backup Battery Replacement
53
Figure 49: Backup Battery Replacement
54
Figure 50: Backup Battery Replacement
54
Backup and Restore
55
Update of the Operating System
55
Figure 51: Backup Battery Replacement
55
Figure 52: Backup Battery Replacement
55
Technical Support and Repairs
56
6 Technical Specifications
57
Technical Data
57
Table 1: System Software Characteristics
57
Table 2: System Hardware Characteristics
58
Table 3: Electrical Characteristics
58
Table 4: Mechanical Characteristics
58
Table 5: Environmental Characteristics
58
Panel Antenna Characteristics
59
Table 6: Panel Antenna Characteristics
59
Table 7: Panel Antenna Characteristics
59
Wall Mount Panel Antenna Characteristics
60
Table 8: Wall Mount Panel Antenna Characteristics
60
Outdoor Panel Antenna Characteristics
61
Table 9: Outdoor Panel Antenna Characteristics
61
Dimension Drawings
62
C6 Router E1-E4
62
Figure 53: Dimensions
62
C6 Router L1-L4
63
Figure 54: Dimensions
63
Panel Antenna Drawing Dimensions
64
Figure 55: Panel Antenna Drawing Dimensions
64
Wall Mount Antenna Drawing Dimensions
65
Figure 56: Wall Mount Antenna Drawing Dimensions
65
Outdoor Panel Antenna Drawing Dimensions
66
Ports PINOUT
66
COM1 - DB15M Serial
66
Figure 57: Outdoor Panel Antenna Drawing Dimensions
66
Digital Input / Output
67
DC Input
67
Table 10: COM - DB15M Serial
67
Table 11: Digital in / out
67
Table 12: DC Input
67
7 Certification
68
Mark of Conformity
68
UL Marking
71
