KEB C6 Instructions For Use

67
TECHNICAL SPECIFICATIONS
6 Data set ready IN
7 Isolated ground -
8 Data terminal ready OUT
9 Carrier detect IN
10 Transmit data + / receive data + (RS-485/RS-422) I/O
11 Transmit data - / receive data - (RS-485/RS-422) I/O
12 Ring indication (RS-232) IN
13 Receive data + (RS-422) IN
14 Receive data - (RS-422) IN
15 N.C. -
Table 10: COM - DB15M serial
Any polarization or termination resistor connected to RS422/485 channel, if
required, it has to be provided by the user.
6.6.2 Digital input / output
8 1
PIN Signal
1 IN 0 +
2 IN 0 -
3 IN 1 +
4 IN 1 -
5 OUT 0 - A
6 OUT 0 - B
7 OUT 1 - A
8 OUT 1 - B
Table 11: Digital IN / OUT
6.6.3 DC input
3 1
PIN Signal
1 Vin +
2 Vin -
3 Earth
Table 12: DC input
