SYSTEM DESCRIPTION
LED Status Description
Reset Steady lighted
Active when pressing the reset button or when
a non-recoverable hardware error occurs.
Power Steady lighted
Active when the COMBIVIS connect Router
device is properly powered
Run/Stop
Steady green
COMBIVIS connect started and connected to
the server
Steady red
COMBIVIS connect started but NOT connect-
ed to the server
Blinking green
COMBIVIS connect started and connecting to
the server
Blinking red
COMBIVIS connect started but not connected
to the server because not associated to any
Domain
Sequence of 2
red blinks
connectionattempttoadi󰀨erentdomainthan
therstoftheinitialregistration
Single 2 green
blinks
CongurationfromUSBsticksuccessfully
completed
Single 2 red
blinks
User credential for Domain access not valid
Single 3 green
blinks
COMBIVIS connect Router device update from
USB stick successfully completed.
Single 3 red
blinks
COMBIVIS connect Router device update from
USB stick failed.
Single 4 red
blinks
Factory restore started
Single 5 red
blinks
COMBIVIS connect Runtime execution error, a
system restart occurs.
Single 6 red
blinks
USB stick data format not correct or unknown
error
Remote
connection
Steady lighted
Active when at least one Control Center client
is connected to the C6 ROUTER E1, other-
wiseo󰀨
COM Rx
COM Tx
Signal presence
These LEDs are directly connected to the
serialportRx/Txsignalsandtheyshowtra󰀩c
through the lines
