Functional Description Digital In- and Outputs
Param. Adr.
min
max
default
ENTER
PROG.
R/W
Step
di.0 2900h ✔ - - 0,0ms 20,0ms 0,1ms 0,5ms -
di.1 2901h ✔ - ✔ 0:PNP 1:NPN 1 PNP -
di.2 2902h ✔ - ✔ 0 127 1 0 bit-coded
di.3 2903h ✔ - ✔ 02214-
di.4 2904h ✔ - ✔ 02215-
di.5 2905h ✔ - ✔ 02213-
di.6 2906h ✔ - ✔ 022115-
di.7 2907h ✔ - ✔ 02210-
di.8 2908h ✔ - ✔ 02210-
di.9 2909h ✔ - ✔ 02210-
di.10 290Ah ✔ - ✔ 02210-
di.11 290Bh ✔ - ✔ 022116-
di.12 290Ch ✔ - ✔ 022117-
di.15 290Fh ✔ - ✔ 0 127 1 0 bit-coded
di.16 2910h ✔ - ✔ 0 127 1 0 bit-coded
di.17 2911h ✔ - ✔ 0 4095 1 0 bit-coded
di.18 2912h ✔ - ✔ 0 4095 1 0 bit-coded
di.19 2913h ✔ - ✔ 0110-
do.0 2A00h ✔✔✔ 0 255 1 0 bit-coded
do.1 2A01h ✔✔✔ 035120-
do.2 2A02h ✔✔✔ 035118-
do.3 2A03h ✔✔✔ 03512-
do.4 2A04h ✔✔✔ 03510-
do.5 2A05h ✔✔✔ 03510-
do.6 2A06h ✔✔✔ 03510-
do.7 2A07h ✔✔✔ 03510-
do.8 2A08h ✔✔✔ 03510-
do.9 2A09h ✔✔✔ 0 255 1 1 bit-coded
do.10 2A0Ah ✔✔✔ 0 255 1 2 bit-coded
do.11 2A0Bh ✔✔✔ 0 255 1 4 bit-coded
do.13 2A0Dh ✔✔✔ 0 255 1 0 bit-coded
do.14 2A0Eh ✔✔✔ 0 255 1 0 bit-coded
do.15 2A0Fh ✔✔✔ 0 255 1 0 bit-coded
6.3.19 Used Parameters
