KEB COMBIVERT F4-F Applications Manual

5
ANTRIEBSTECHNIK
5
Parameter
5
1
5
KEB COMBIVERT F4-C
Name: Basis
Section PageDate
© KEB Antriebstechnik, 1999
All Rights reserved
Chapter
21.06.99
ru - Parameter Addr.
min
max
default
[?] see Page(s)
ru 0 inverter state 2000 - - - 0 111 table –– –– 6.1.5, 6.12.4
ru 1 actual speed display 2001 - - - -9999,5 9999,5 0,5 –– rpm 6.1.8, 6.5.5
ru 2 actual torque display 2002 - - - 0,0 1000,0 0,1 –– Nm 6.1.8, 6.5.5
ru 4 set speed display 2004 - - - -9999,5 9999,5 0,5 –– rpm 6.1.8, 6.5.5
ru 7 actual inverter utilization 2007 - - - 0 200 1 –– % 6.1.9, 6.3.11
ru 8 peak inverter utilization 2008 - - ✓ 0 200 1 –– % 6.1.9
ru 9 apparent current 2009 - - - 0 *) 0,1 –– A 6.1.9
ru 10 active current 200A - - - 0 *) 0,1 –– A 6.1.9, 6.3.11, 6.5.5
ru 11 actual DC voltage 200B - - - 200 999 1 –– V 6.1.9
ru 12 peak DC voltage 200C - - ✓ 200 999 1 –– V 6.1.10
ru 14 input terminal state 200E - - - 0 127 1 –– –– 6.1.10, 6.3.4
ru 15 output terminal state 200F - - - 0 247 1 –– –– 6.1.10, 6.3.15
ru 16 internal input state 2010 - - - 0 3967 1 –– –– 6.1.11, 6.3.8
ru 17 internal output state 2011 - - - 0 255 1 –– –– 6.1.11
ru 18 actual parameter set 2012 - - - 0 7 1 –– –– 6.1.12
ru 20 speed REF display 2014 - - - -9999,5 9999,5 0,5 –– rpm 6.1.12
ru 22 REF 1 display 2016 - - - -100,0 100,0 0,1 –– % 6.1.12
ru 23 REF 2 display 2017 - - - -100,0 100,0 0,1 –– % 6.1.12
ru 24 OL counter display 2018 - - - 0 100 1 –– % 6.1.12
ru 25 peak apparent current 2019 - - ✓ 0 *) 0,1 –– A 6.1.13
ru 26 actual speed master 201A - - - -9999,5 9999,5 0,5 –– rpm 6.1.13
ru 27 angular deviation 201B - - - -360,0 360,0 0,1 –– ° 6.1.13
ru 28 speed deviation 201C - - - -9999,5 9999,5 0,5 –– rpm 6.1.13
ru 29 heat sink temperature 201D - - - 0 100 1 –– °C 6.1.13
ru 31 power on counter 201F - - - 0 65535 1 –– h 6.1.14
ru 32 modulation on counter 2020 - - - 0 65535 1 –– h 6.1.14
ru 35 actual position sign 2023 - - - 0 1 1 –– inc 6.1.14, 6.11.4
ru 36 actual position high 2024 - - - 0 65535 1 –– inc 6.1.14, 6.11.4
ru 37 actual position low 2025 - - - 0 65535 1 –– inc 6.1.15, 6.11.4
ru 38 set position sign 2026 - - - 0 1 1 –– inc 6.1.15, 6.11.4
ru 39 set position high 2027 - - - 0 65535 1 –– inc 6.1.15, 6.11.4
ru 40 set position low 2028 - - - 0 65535 1 –– inc 6.1.15, 6.11.4
SP - Parameter Addr.
min
max
default
[?] see Page(s)
SP 0 speed setting source 3000 ✓✓ ✓ 0181 2–– 6.4.6
SP 1 speed setting absolut 3001 ✓ - ✓ -9999,5 9999,5 0,5 0,0 rpm 6.4.5
SP 2 speed setting % 3002 ✓ - ✓ -100,0 100,0 0,1 0,0 % 6.4.5
SP 3 rotation setting 3003 ✓✓ ✓ 021 0–– 6.4.6
SP 4 minimal speed reference forward 3004 ✓ - ✓ 0,0 9999,5 0,5 0,0 rpm 6.4.7
SP 5 maximal speed reference forward 3005 ✓ - ✓ 0,0 9999,5 0,5 2100,0 rpm 6.4.7
SP 6 minimal speed reference reverse 3006 ✓ - ✓ 0,0 9999,5 0,5 -1 : off rpm 6.4.7
SP 7 maximal speed reference reverse 3007 ✓ - ✓ 0,0 9999,5 0,5 -1 : off rpm 6.4.7
SP 8 absolute maximum speed forward 3008 - - ✓ 0,0 9999,5 0,5 6000,0 rpm 6.4.7
SP 9 absolute maximum speed reverse 3009 - - ✓ 0,0 9999,5 0,5 -1 : off rpm 6.4.7
SP 11 acceleration time forward 300B ✓ - ✓ 0,00 320,00 0,01 2,00 sec 6.4.10
SP 12 deceleration time forward 300C ✓ - ✓ 0,00 320,00 0,01 2,00 sec 6.4.10
SP 13 acceleration time reverse 300D ✓ - ✓ 0,00 320,00 0,01 -1 : off sec 6.4.10
SP 14 deceleration time reverse 300E ✓ - ✓ 0,00 320,00 0,01 -1 : off sec 6.4.10
SP 15 s-curve accelerate forward 300F ✓ - ✓ 0,00 5,00 0,01 0,00 sec 6.4.12
SP 16 s-curve decelerate forward 3010 ✓ - ✓ 0,00 5,00 0,01 -1 : off sec 6.4.12
SP 17 s-curve accelerate reverse 3011 ✓ - ✓ 0,00 5,00 0,01 -1 : off sec 6.4.12
SP 18 s-curve decelerate reverse 3012 ✓ - ✓ 0,00 5,00 0,01 -1 : off sec 6.4.12
SP 22 jogging speed 3016 - - ✓ 0,0 6000,0 0,5 100,0 rpm
SP 26 motorpoti function 301A - - ✓ 0151 0–– 6.8.12
SP 27 motorpoti time 301B - - ✓ 0,00 300,00 0,01 128,00 sec 6.8.12
Pn - Parameter Addr.
min
max
default
[?] see Page(s)
Pn 0 automatic retry UP 2200 - - ✓ 011 0–– 6.6.6
Pn 1 automatic retry OP 2201 - - ✓ 011 0–– 6.6.6
Pn 7 speed search condition 2207 ✓ - ✓ 0151 8–– 6.6.5, 6.6.6
5.1.2 Parameterlisting
F4-F
*) dependent by the inverter size
Parameter: 9 writable
- readable only
Parameter: 9 set programmable
- not programmable
Enter parameter:9 active after „Enter“
- active immediately
Value range
Lower limit / Upper limit
DescriptionUnit
Default value
Resolution, increments
Parameter address
Parameter group
