KEB COMBIVERT F4-F Applications Manual

25
ANTRIEBSTECHNIK
61125
KEB COMBIVERT F4-F
Name: Basis
17.06.99
6
Section PageDate
© KEB Antriebstechnik, 1999
All Rights reserved
Chapter
Functional DescriptionPositioning Module
Param. Adr.
min
max
default
ENTER
PROG.
R/W
Step
Pc.0 3600h ✔ - ✔ 0110-
Pc.1 3601h ✔ - ✔ 0313-
Pc.4 3604h ✔ -- 0 1 1 2 -
Pc.5 3605h ✔ - - 0 inc 65535 inc 1 inc 8000h inc -
Pc.6 3606h ✔ - - 0 inc 65535 inc 1 inc 0 inc -
Pc.7 3607h ✔ -- 0 1 1 2 -
Pc.8 3608h ✔ - - 0 inc 65535 inc 1 inc 7FFFh inc -
Pc.9 3609h ✔ - - 0 inc 65535 inc 1 inc FFFFh inc -
Pc.10 360Ah ✔ - ✔ 0510-
Pc.11 360Bh ✔ -- 0 1 1 0 -
Pc.12 360Ch ✔ - - 0 65535 1 0 -
Pc.13 360Dh ✔ - - 0 65535 1 0 -
Pc.14 360Eh ✔ - - -3000,0 rpm 3000,0 rpm 0,5 rpm 100,0 rpm -
Pc.16 3610h ✔ - ✔ 0111-
Pc.17 3611h ✔ - ✔ 1,00 250,00 0,01 1,00 -
Pd.0 3700h ✔✔ -0 2 1 0-
Pd.1 3701h ✔ - ✔ 0410-
Pd.2 3702h ✔✔ - 0 65535 1 30 -
Pd.3 3703h ✔✔ - 0,0 rpm 500,0 rpm 0,5 rpm 250,0 rpm -
Pd.5 3705h ✔✔ - 0,01 s 8,00 s 0,01 s 0,10 s -
Pd.6 3706h ✔✔ - 0,01 s 8,00 s 0,01 s 1,0 s -
Pd.7 3707h ✔✔ - 0 rpm 10000 rpm 1 rpm 1000 rpm -
Pd.8 3708h ✔✔ -0 1 1 0-
Pd.9 3709h ✔✔ - 0 inc 65535 inc 1 inc 0 inc -
Pd.10 370Ah ✔✔ - 0 inc 65535 inc 1 inc 0 inc -
Pd.11 370Bh ✔✔ -0 1 1 0-
Pd.12 370Ch ✔✔ - 0 inc 65535 inc 1 inc 1000 inc -
