Functional Description
© KEB Antriebstechnik, 1999
All Rights reserved
Chapter Section PageDate
Adr.
min max
default
2000h
0
111
-
-
-
6.1.4 Description of ru-Parameter
ru. 0 Inverter state
ru-Parameter
In parameter „inverter status“ the actual operating condition of the frequency inverter is displayed. The operating conditions
can be devided into four groups:
1. Ready for operation signals
2. Process signals
3. Fault signals
4. Error messages
1. Ready for operation signals
These signals are given upon completion of initialization and when the frequency inverter is ready for operation:
Display Bus Meaning
noP 0 no Operation - control release (terminal X2.1) not activated
- modulation disabled
- output voltage = 0 V/drive without control
LS 70 Low Speed - control release (terminal X2.1) active
- rotation setting is missing
- modulation disabled
- output voltage = 0 V/drive without control
2. Process signals
The signals occur during the normal operation of the frequency inverter:
Display Bus Meaning (drive conditions refer to the setpoint value)
FAcc 64 Forward Acceleration - drive accelerates with rotation forward
FdEc 65 Forward Deceleration - drive decelerates with rotation forward
Fcon 66 Forward Constant - drive operates with constant speed and rotation forward
rAcc 67 Reverse Acceleration - drive accelerates with rotation reverse
rdEc 68 Reverse Deceleration - drvie decelerates with rotation reverse
rcon 69 Reverse Constant - drive operates with constant speed and rotation reverse
rFP 79 Ready for Positioning - positioning module active
- drive is in „off“-positon and waits for positioning command
PA 80 Positioning Active - positioning module active
- drive carries out positioning command
SrA 82 Search for - positioning or synchronous module active
Reference Active - drive performs reference point run
