6.8.2 Adjustment
Assistant
In combination with the program „Inverter Scope“ the following parameters give
assistance with regard to the adjustment of the inverter. The program functions like a
4-channel oscilloscope.
The four channels are adjusted to any parameter address by way of AA.0...AA.3,
which are given out over AA.10…AA.13. With AA.4...AA.9 the time basis as well as
the trigger point are defined.
At the parameters AA.10...AA.13 the adjusted values for channel 1...4 are given out.
A direct access to these parameters is not necessary since the „Inverter Scope“ is
equipped with its own operator surface and has program-internal access to the AA-
parameters. The handling of the „Inverter Scope“ is explained in the COMBIVIS
Instruction Manual.
Adr.
min max
default
1
-
0
655350
s.a.
These parameters contain the addresses of the parameters which shall be recorded by the „inverter scope“.
AA.0 Graph 1 parameter selection 3200h
AA.1 Graph 2 parameter selection 3201h
AA.2 Graph 3 parameter selection 3202h
AA.3 Graph 4 parameter selection 3203h
3204h
0,001
-
0,001
32,0000,001
This parameter contains the time basis for the recording of the parameter values.
AA.4 Time base
Adr.
min max
default
3205h
1
-
255
2550
AA.5 Trigger source
Adr.
min max
default
3206h
1
-
10
variable0
AA.6 Trigger position
