KEB COMBIVERT F4-F Applications Manual

Parameter
51
KEB COMBIVERT F4-C
10
Name: Basis
Chapter
Section Page Date
© KEB Antriebstechnik, 1999
All Rights reserved
21.06.99
Pc 5 limit switch left high 3605 - - ✓ 0 65535 1 8000h inc 6.11.7
Pc 6 limit switch left low 3606 - - ✓ 0 65535 1 0 inc 6.11.7
Pc 7 limit switch right sign 3607 - - ✓ 011 2–– 6.11.7
Pc 8 limit switch right high 3608 - - ✓ 0 65535 1 7fffh inc 6.11.7
Pc 9 limit switch right low 3609 - - ✓ 0 65535 1 ffffh inc 6.11.7
Pc 10 mode of position reference 360A - ✓✓ 031 0–– 6.11.11
Pc 11 reference point sign 360B - - ✓ 011 0–– 6.11.11
Pc 12 reference point high 360C - - ✓ 0 65535 1 0 –– 6.11.11
Pc 13 reference point low 360D - - ✓ 0 65535 1 0 –– 6.11.11
Pc 14 reference speed 1 360E - - ✓ -3000,0 3000,0 0,5 100,0 rpm 6.10.4, 6.11.10
Pc 16 encoder mode for positioning 3610 - ✓✓ 011 0–– 6.11.8
Pc 17 gear factor for positioning 3611 - ✓✓ 1,00 250,00 0,01 1,00 –– 6.11.8
Pd - Parameter Addr.
min
max
default
[?] see Page(s)
Pd 0 posi mode 3700 ✓ - ✓ 021 0–– 6.11.3
Pd 1 manuell start 3701 - ✓✓ 041 0–– 6.10.4, 6.11.9, 6.11.10
Pd 2 Kp position 3702 ✓ - ✓ 0 65535 1 30 –– 6.11.9
Pd 3 limit for Kp position 3703 ✓ - ✓ 0,0 500,0 0,5 250,0 rpm 6.11.8, 6.11.9
Pd 5 s curve time 3705 ✓ - ✓ 0,01 8,00 0,01 0,10 s 6.11.8, 6.11.9
Pd 6 acceleration time 3706 ✓ - ✓ 0,01 8,00 0,01 1,00 s 6.11.8, 6.11.9
Pd 7 max speed for position 3707 ✓ - ✓ 0 10000 1 1000 rpm 6.11.8, 6.11.9
Pd 8 set position sign 3708 ✓ - ✓ 011 0–– 6.11.8, 6.11.9
Pd 9 set position high 3709 ✓ - ✓ 0 65535 1 0 inc 6.11.4, 6.11.5, 6.11.6
Pd 10 set position low 370A ✓ - ✓ 0 65535 1 0 inc 6.11.4, 6.11.5, 6.11.6
Pd 11 mode of positioning 370B ✓ - ✓ 011 0–– 6.11.7
Pd 12 position deviation 370C ✓ - ✓ 0 65535 1 1000 inc 6.11.7
AA - Parameter Addr.
min
max
default
[?] see Page(s)
AA 0 graph 1 parameter selection 3200 - - ✓ 0 65535 1 2001 –– 6.8.7
AA 1 graph 2 parameter selection 3201 - - ✓ 0 65535 1 -1 : off –– 6.8.7
AA 2 graph 3 parameter selection 3202 - - ✓ 0 65535 1 -1 : off –– 6.8.7
AA 3 graph 4 parameter selection 3203 - - ✓ 0 65535 1 -1 : off –– 6.8.7
AA 4 time base 3204 - - ✓ 0,001 32,000 0,001 0,001 sec 6.8.7
AA 5 trigger source 3205 - - ✓ 0 4095 1 6 –– 6.8.7
AA 6 trigger position 3206 - - ✓ 0 100 1 50 –– 6.8.7
AA 7 syncronisation 3207 - - ✓ -32767 32767 1 0 –– 6.8.8
AA 8 trigger status 3208 - - ✓ 021 0–– 6.8.8
AA 9 select graph address 3209 - - ✓ 0 1999 1 0 –– 6.8.8
AA 10 read graph 1 320A - - - 0 1 –– 6.8.8
AA 11 read graph 2 320B - - - 0 1 –– 6.8.8
AA 12 read graph 3 320C - - - 0 1 –– 6.8.8
AA 13 read graph 4 320D - - - 0 1 –– 6.8.8
