KEB COMBIVERT S4 User Manual

E 17
ANTRIEBSTECHNIK
5. Dimensions
Size A B B1 B2 B3 C C1 F G H Weight [kg]
D 90 250 264 287,5 301,5 160 210 5 45 240 2,0
E 130 290 - 327,5 - 200 - 7 65 275 3,6
Size a
1
a
2
a
3
bcdef k
1
k
2
lpSS
2
js6 k6 k
0
k
B
m
R
m
G
m
RB
m
GB
M1 74 40 63 11 2,5 9 10,2 3 73 98 31 37 20 121 - 145 - M3 55 5,8
M2 74 40 63 11 2,5 9 10,2 3 86 110 31 37 20 133 - 157 - M3 55 5,8
M3 74 40 63 11 2,5 9 10,2 3 98 122 31 37 20 145 - 169 - M3 55 5,8
M4 74 40 63 11 2,5 9 10,2 3 122 147 31 37 20 170 - 194 - M3 55 5,8
01 116 80 100 8 3 14 16 5 86 132 46 37 30 156 193 192 229 M4 92 7
02 116 80 100 8 3 14 16 5 110 156 46 37 30 180 217 226 263 M4 92 7
03 116 80 100 8 3 14 16 5 144 190 46 37 30 214 251 260 297 M4 92 7
04 116 80 100 8 3 14 16 5 178 224 46 37 30 248 285 294 331 M4 92 7
11 136 95 115 10 3 19 21,5 6 133 141 52 37 40 218 248 226 256 M6 110 9
12 136 95 115 10 3 19 21,5 6 163 171 52 37 40 248 278 256 286 M6 110 9
13 136 95 115 10 3 19 21,5 6 193 201 52 37 40 278 308 286 316 M6 110 9
14 136 95 115 10 3 19 21,5 6 223 231 52 37 40 308 338 316 346 M6 110 9
21 187 130 165 17 3,5 24 27 8 142 187 45 37 50 231 263 276 308 M8 140 11
22 187 130 165 17 3,5 24 27 8 172 217 45 37 50 261 293 306 338 M8 140 11
23 187 130 165 17 3,5 24 27 8 202 247 45 37 50 291 323 336 368 M8 140 11
24 187 130 165 17 3,5 24 27 8 247 292 45 37 50 336 368 381 413 M8 140 11
c
l b
øa
2
k 1
S
2
S
a
1
a
3
d
k6
e
f
k
k
2
5.2 Dimensions Servo Motor
Featherkey to DIN 6885/1 * k
0
Dimensions without brake * m
R
Dimensions with Resolver
Centring to DIN 332/2 k
B
Dimensions with brake m
G
Dimensions with Encoder (ERN 1387)
m
RB
Dimensions with Resolver and brake
m
GB
Dimensions with Encoder (ERN 1387) and brake
B1/C1 Dimensions with base filter B2 Dimensions with shield plate B3 Dimensions with base filter and shield plate
5.1 Dimensions Servo Controller
POWER XXXXXXXXXXXX
INPUT
OUTPUT
KEB Antriebstechnik
Karl E. Brinkmann GmbH
D-32677 Barntrup
Made in Germany
VOLTAGE
CYCLE
XXXXXXXXXXX
XXXXXXXXXXX
VOLTAGE
CURRENT
VER-NO.
ART-NO.
SER-NO.
XXXXXXXXXXXXXXX˜
95000001/XXXXXXX
XX.F4.XXX-XXXX
XXXXXXXXXXXX
XXXXXXXXXX
AC-MOT.
4,0 KW, 2/4 P, 50/60 HZ
POWER XXXXXXXXXXXX
INPUT
OUTPUT
KEB Antriebstechnik
Karl E. Brinkmann GmbH
D-32677 Barntrup
Made in Germany
VOLTAGE
CYCLE
XXXXXXXXXXX
XXXXXXXXXXX
VOLTAGE
CURRENT
VER-NO.
ART-NO.
SER-NO.
XXXXXXXXXXXXXXX˜
95000001/XXXXXXX
XX.F4.XXX-XXXX
XXXXXXXXXXXX
XXXXXXXXXX
AC-MOT.
4,0 KW, 2/4 P, 50/60 HZ
START
STOP
FUNC.
SPEE
ENTE
F/R
ANTRIEBSTECHNIK
START
STOP
FUNC.
SPEE
ENTE
F/R
ANTRIEBSTECHNIK
C / C1 G
A
B
H
B1
B2
B3
∅F
m
k* m*
p (Centring DR DIN332/2)
