E 40
10. Accessories
The servo controller KEB COMBIVERT S4 can be supplied ex factory with internal
radio interference suppression filter. Base filters are available for the unit sizes 03,
05 and 10.
Unit size 10 can only be delivered with an external filter.
10.2 Radio Interference
Suppression Filter
10.2.1 Technical Data
L
N
PE
M
3 ~
PE
W
U
V
L1
L2
PE
Radio Interference Suppression Filter Servo Controller
10.2.2 Connection
Connection 1-phase
L2
L3
PE
M
3 ~
PE
W
U
V
L2
L3
PE
L1
L1
Radio Interference Suppression Filter Servo Controller
Connection 3-phase
10.2.3 Dimensions
12.U4.00E-CM00
Servo controller Part.No.: I
N
[A] U
N
[V]
Filter-kit Rated current Rated voltage
03 (D-Housing)
1)
07.U4.00D-B600
2)
12 250
05 (D-Housing)
1)
07.U4.00D-B600
2)
12 250
10 (D-Housing)
1)
10.U4.00D-BM00 8 500
12 (E-Housing) 12.U4.00E-CM00 22 500
290
275
200
80
40
Ø 6
1)
Dimensions Servo controller with base filter see Page E 17
2)
only for 1-phase Servo controller
