E 26
7. Operation
Parameter Parameter Name Setting Range Resolution Factory Setting
number
CP.0 Password input 0…9999 1
CP.1 Actual speed display 0,5 U/min
* CP.2 Status display
* CP.3 Apparent motor current 0,1 A
* CP.4 Max. apparent motor current 0,1 A
CP.5 Current Torque 0,1 Nm
CP.6 Setpoint speed display 0,5 U/min
CP.7 Acceleration time 0…320 s 0,01 s 0,05 s
CP.8 Deceleration time 0…320 s 0,01 s 0,05 s
CP.9 Torque limit 0…5 x M
N
0,1 Nm 3 x M
N
CP.10 Max. setpoint speed 0…9999 0,5 U/min Rated speed
CP.11 Jogging speed 0…9999 0,5 U/min 100 U/min
CP.12 P-factor speed controller 0…65535 1 Motor-type dependent
CP.13 I-factor speed controller 0…65535 1 Motor-type dependent
CP.14 Line number incremental encoder simulation - - 512 / 2048
CP.15 Behaviour at external fault 0…6 1 0
CP.16 Offset REF 1 -100%…+100 % 0,1 % 0 %
CP.17 Zero point hysteresis REF 1 0…10 % 0,1 % 0 %
CP.18 Function output A1 0…6 1 2
CP.19 Amplification output A1 -20…+20 0,01 3 x M
Rated
= +10 V
CP.20 Amplification output A2 -20…+20 0,01 +/–n
Rated
= +/–10 V
CP.21 Switching condition output D1 0…20 1 20
CP.22 Switching condition output D2 0…20 1 18
CP.23 Torque level output D1 0…50 Nm 0,1 Nm 0,5 x M
Rated
CP.24 Speed level output D2 0…16000 U/min 0,5 U/min 0,5 x n
Rated
7.2 Parameter Survey
^
^
Read-Only Parameters
can only be read they
cannot be changed.
(CP.1 …CP.6, CP.14)
ENTER-Parameters
are programmable parameters a
change must be confirmed with
the ENTER-key before it is
accepted and stored.
(CP.0, CP.15, CP.18, CP.21, CP.22)
CP-Parameter
(CP.0 … CP.24)
Programmable Parameters
can be changed (CP.0,
CP.7 … CP.13, CP.15 … CP.24)
NO-ENTER-Parameters
are programmable parameters, a
change is accepted and stored
immediately.
(CP.7 … CP.13, CP.16, CP.17,
CP.19, CP.20, CP.23, CP.24)
7.1 Parameter Structure
* With the actual values displayed, from the normal machine dispersion and temperature drifts,
tolerances must be taken into account. (about ± 10% in relation to the nominal value)
