KEB COMBIVERT S4 User Manual

E 4
1.1 KEB COMBIVERT S4
1. Introduction
The servo system KEB COMBIVERT S4 consists of the components:
– digital servo controller KEB COMBIVERT S4 (230V- or 400V class)
– synchronous servo motor KEB COMBIVERT SM
The synchronous servo motor is also available with
brake.
Refer to "Accessories Braking Motor " (page E 41)
Servo System
Regarding prefabricated motor, resolver and encoder
cables refer to "Accessories Cable " (page E 23).
1.3 Application
The digital servo controller KEB COMBIVERT S4 serves exclusively for the control
and regulation of the supplied synchronous servo motor KEB COMBIVERT SM.
The servo system KEB COMBIVERT S4 is a highly dynamic control drive it is
connected and ready for operation within a short time.
1.2 Part Code
03.S4.D20–3001
Sub-assembly 001 = Resolver / Incremental encoder simulation
002 =
Resolver / Inc. enc. sim. / Interference suppression
003 = ERN 1387 / Incremental encoder simulation
004 = ERN 1387 / Inc. enc. sim. / Interf. suppr.
005 = Resolver / Incremental encoder input
006 = Resolver / Inc. enc. inp. / Interf. suppr.
007 = ERN 1387 / Inc. enc. inp.
008 = ERN 1387 / Inc. enc. inp. / Interf. suppr.
Rated speed 1 = 1500 U/min
2 = 2000 U/min
3 = 3000 U/min
4 = 4000 U/min
6 = 6000 U/min
Mechanic construc- 0 = without brake / with featherkey to DIN
tion of the motor 1 = with brake / with featherkey to DIN
2 = without brake / without featherkey
3 = with brake / without featherkey
E = replacement part
Supply voltage 2 = 200 V class
4 = 400 V class
Housing design D or E
Unit designation S4
Unit size M1…M4, 01…04, 11…14, 21…24
